SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter

    Buy cheap SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter from wholesalers

    Buy cheap SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter from wholesalers
    • Buy cheap SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter from wholesalers
    • Buy cheap SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter from wholesalers
    • Buy cheap SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter from wholesalers

    SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter

    Ask Lasest Price
    Brand Name : DYS/OEM
    Model Number : SC/APC Pigtail
    Certification : IS09001-2015.ROHS
    Price : Negotiable
    Payment Terms : T/T or L/C,Western Union or Paypal
    Supply Ability : 500000PCS / Month
    Delivery Time : 3-5 work days
    • Product Details
    • Company Profile

    SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter

    SC APC G657A1 Fiber Optic Patch Cord 0.9mm Fiber Optics Pigtail 1 Meter


    Sc/APC G657A1 0.9mm Fiber Optics Pigtail with 1 Meter


    Fiber optic pigtail is a fiber optic cable terminated with a factory-installed connector on one end, leaving the other end unterminated. Hence the connector side can be linked to equipment and the other side melted with optical fiber cables. Fiber optic pigtail are utilized to terminate fiber optic cables via fusion or mechanical splicing. High quality pigtail cables, coupled with correct fusion splicing practices offer the best performance possible for fiber optic cable terminations. Fiber optic pigtails are usually found in fiber optic management equipment like ODF, fiber terminal box and distribution box.. ETC


    Performance Index

    ItemSM(Single Mode)MM(Multimode)
    Fiber Cable TypeG652D/G657A1/G6572/G655/G657BOM1OM2/OM3/OM4
    Fiber Diameter (um)9/12562.5/12550/125
    Cable OD (mm)0.9/1.6/1.8/2.0/2.4/3.0
    Endface TypePCUPCAPCUPCUPC
    Typical Insertion Loss (dB)<0.2<0.15<0.2<0.1<0.1
    Return Loss (dB)>45>50>60/
    Insert-pull Test (dB)<0.2<0.3<0.15
    Interchangeability (dB)<0.1<0.15<0.1
    Anti-tensile Force (N)>70
    Temperature Range (℃)-40~+80
